Сборка кольца ERPS. Особенности: линки LACP, два кольца. Juniper 13 Настройка ERPS Ethernet Ring Protection Switching на коммутаторах EX • Juniper 13 Настройка ERPS Ethernet Ring Pr... ////////////SWL3_1 vlan batch 101 to 104 stp region-configuration instance 1 vlan 10 101 102 instance 2 vlan 20 103 104 active region-configuration erps ring 1 control-vlan 10 protected-instance 1 ////raps-mel 0 version v2 erps ring 2 control-vlan 20 protected-instance 2 ////raps-mel 0 version v2 interface Eth-Trunk1 port link-type trunk undo port trunk allow-pass vlan 1 port trunk allow-pass vlan 101 to 104 stp disable erps ring 1 erps ring 2 mode lacp interface XGigabitEthernet0/0/1 port link-type trunk undo port trunk allow-pass vlan 1 port trunk allow-pass vlan 101 to 104 stp disable erps ring 1 rpl owner erps ring 2 interface XGigabitEthernet0/0/3 eth-trunk 1 interface XGigabitEthernet0/0/4 eth-trunk 1 ////////////SWL3_2///////////////////// vlan batch 101 to 104 stp region-configuration instance 1 vlan 10 101 102 instance 2 vlan 20 103 104 active region-configuration erps ring 1 control-vlan 10 protected-instance 1 version v2 erps ring 2 control-vlan 20 protected-instance 2 version v2 interface Eth-Trunk1 port link-type trunk undo port trunk allow-pass vlan 1 port trunk allow-pass vlan 101 to 104 stp disable erps ring 1 erps ring 2 mode lacp interface XGigabitEthernet0/0/1 port link-type trunk undo port trunk allow-pass vlan 1 port trunk allow-pass vlan 101 to 104 stp disable erps ring 1 erps ring 2 rpl owner interface XGigabitEthernet0/0/3 eth-trunk 1 interface XGigabitEthernet0/0/4 eth-trunk 1 //////////////SWL2_1///SWL2_2 vlan batch 101 to 104 stp region-configuration instance 1 vlan 10 101 102 instance 2 vlan 20 103 104 active region-configuration erps ring 1 control-vlan 10 protected-instance 1 version v2 erps ring 2 control-vlan 20 protected-instance 2 version v2 interface Eth-Trunk1 port link-type trunk undo port trunk allow-pass vlan 1 port trunk allow-pass vlan 101 to 104 stp disable erps ring 1 erps ring 2 mode lacp interface XGigabitEthernet0/0/1 port link-type trunk undo port trunk allow-pass vlan 1 port trunk allow-pass vlan 101 to 104 stp disable erps ring 1 erps ring 2 interface XGigabitEthernet0/0/3 eth-trunk 1 interface XGigabitEthernet0/0/4 eth-trunk 1 interface XGigabitEthernet0/0/2 port link-type trunk undo port trunk allow-pass vlan 1 port trunk allow-pass vlan 101 to 104 Уважаемые зрители! Если видео лекции/практики оказалось полезным, поддержите ролик лайком и комментарием, это поможет ознакомить с ним большую аудиторию. Спасибо. Анонсы, обсуждения, вопросы тут:
