Домашняя работа eNSP 2. VLAN. (Лекция 6)

Собираем начальную L2 топологию из 4-х коммутаторов, настраиваем VLAN, и порты trunk и access. Курс Huawei HCIA Datacom. Лекция 6. Принципы и конфигурация VLAN. Trunk, Access, Hybrid.    • Курс Huawei HCIA Datacom. Лекция 6. Принци...   Быстрее и в полном объеме домашние работы eNSP можно смотреть тут:
Анонсы, обсуждения, вопросы тут:
\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\SW_L2_1-2\\\\\\\\\\\\\\\\\\\\\\\\\\ sysname SW_L2_1 vlan batch X1 to X3 X9 interface Ethernet0/0/1 port link-type access port default vlan X1 interface Ethernet0/0/2 port link-type access port default vlan X2 interface GigabitEthernet0/0/1 port link-type trunk port trunk allow-pass vlan X1 to X3 X9 interface GigabitEthernet0/0/2 port link-type trunk port trunk allow-pass vlan X1 to X3 X9 \\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\SW_L3_1 sysname SW_L3_1 vlan batch X1 to X3 X9 interface GigabitEthernet0/0/1 port link-type access port default vlan X9 interface GigabitEthernet0/0/21 port link-type trunk port trunk allow-pass vlan X1 to X3 X9 interface GigabitEthernet0/0/22 port link-type trunk port trunk allow-pass vlan X1 to X3 X9 interface GigabitEthernet0/0/23 port link-type trunk port trunk allow-pass vlan X1 to X3 X9 ////////////////////////////////////////////SW_L3_2////////////////// sysname SW_L3_2 vlan batch X1 to X3 X9 interface GigabitEthernet0/0/1 port link-type access port default vlan X3 interface GigabitEthernet0/0/21 port link-type trunk port trunk allow-pass vlan X1 to X3 X9 interface GigabitEthernet0/0/22 port link-type trunk port trunk allow-pass vlan X1 to X3 X9 interface GigabitEthernet0/0/23 port link-type trunk port trunk allow-pass vlan X1 to X3 X9 Проверка: disp cur disp vlan disp port vlan
